Pvc Coated Wire Rope

Brand
Capacity

Brand

Lifmex

About This Product

PVC Coated

Main Applications: Widely used in automobiles, ship building, construction industry and all needs of outdoor applications or special working environment.

Mainly used in mine hoist cage, meat processing plant, upgrade machinery, ship anchors and fishing operations, fishing vessels trawling.

Min Order Quantity: 1

Technical Details

Nominal Diameter (mm)	Minimum Breaking Strength (kN) Nominal Tensile Strength (N/mm²)		Approx N.W. (kg/100mtr)
Nominal Diameter (mm)	1770 N/mm²	1960 N/mm²	Approx N.W. (kg/100mtr)
2–3	1.48	1.64	1.57
3–5	3.33	3.69	4.08
4–6	5.92	6.56	6.29
6–8	13.3	–	12.22
8–10	23.7	–	20.2
10–12	38.8	–	–
12–14	54.2	–	–

Nominal Diameter (mm)	Minimum Breaking Strength (kN) Nominal Tensile Strength (N/mm²)		Approx N.W. (kg/100mtr)
Nominal Diameter (mm)	1770 N/mm²	1960 N/mm²	Approx N.W. (kg/100mtr)
2–3	2.35	2.6	2
3–5	5.29	5.86	5.04
4–6	9.41	10.4	8

Nominal Diameter (mm)	Minimum Breaking Strength (kN) Nominal Tensile Strength (N/mm²)		Approx N.W. (kg/100mtr)
Nominal Diameter (mm)	1770 N/mm²	1960 N/mm²	Approx N.W. (kg/100mtr)
2–3	1.48	1.64	1.57
3–5	3.33	3.69	4.08
4–6	5.92	6.56	6.29
6–8	13.3	–	12.22
8–10	23.7	–	20.2
10–12	38.8	–	–
12–14	54.2	–	–
