Counter Balance Electric Stacker

Brand
Capacity

Brand

Lifmex

Capacity

1500 KG

About This Product

A Cost-efficient Stacker that combines the versatility of a counterbalance forklift with the operational benefits of a Pedestrian Stacker.

It moves heavy loads from one place to another without the need for oversized fork truck equipment.

Min Order Quantity: 1

Technical Details

Product Code		LBES1530
Mast Type		Duplex
Mast Profile		H Model
Type of Drive		Full Electric
Operator Type		Rider
Capacity		(Q) kg	1500
Load Center		(C) mm	600
Wheel Type		PU (Polyurethane)
Mast Lower Height		(h1) mm	2055
Mast Extend Height		(h2) mm	3810
Lifting Height		(h) mm	70~3000
Fork Length		(slell) mm	1070
Rear Body Width		(W1) mm	850
Overall Width		(W2) mm	990
Overall Length (with platform)		(L) mm	3250
Height of tiller arm in drive position min/max		(H) mm	1030~1270
Rear Body Height		(H1) mm	860
Overall Fork Width		(W) mm	200~680
Min Turning Radius		(Wα) mm	1633
Lowered Height of Fork		(H3) mm	70
Travel Speed	Laden	km/h	5
Travel Speed	Unladen	km/h	5.3
Lift Speed	Laden	mm/s	90
Lift Speed	Unladen	mm/s	100
Lower Speed	Laden	mm/s	210
Lower Speed	Unladen	mm/s	80
Approximate N.W. with Battery		kg	1830

Counterbalance design allows the operator complete access to three sides of the load. The open front enables the forks to be next to workstation for easy loading and unloading.

Counter Balance Stackers can be found working on loading docks, in stock rooms and on manufacturing floors, where durability and dependability are crucial. With its compact dimensions suited to confined areas, and legless design, the stacker can be used to lift practically anything you can think of as there are no “legs” to get in the way.

Product Code		LBES1530
Mast Type		Duplex
Mast Profile		H Model
Type of Drive		Full Electric
Operator Type		Rider
Capacity		(Q) kg	1500
Load Center		(C) mm	600
Wheel Type		PU (Polyurethane)
Mast Lower Height		(h1) mm	2055
Mast Extend Height		(h2) mm	3810
Lifting Height		(h) mm	70~3000
Fork Length		(slell) mm	1070
Rear Body Width		(W1) mm	850
Overall Width		(W2) mm	990
Overall Length (with platform)		(L) mm	3250
Height of tiller arm in drive position min/max		(H) mm	1030~1270
Rear Body Height		(H1) mm	860
Overall Fork Width		(W) mm	200~680
Min Turning Radius		(Wα) mm	1633
Lowered Height of Fork		(H3) mm	70
Travel Speed	Laden	km/h	5
Travel Speed	Unladen	km/h	5.3
Lift Speed	Laden	mm/s	90
Lift Speed	Unladen	mm/s	100
Lower Speed	Laden	mm/s	210
Lower Speed	Unladen	mm/s	80
Approximate N.W. with Battery		kg	1830
